The AirQuality local layout provides a full-page layout containing AQI data ranging from current, hourly forecast, and nearby stations. Additionally, this layout includes a Leaflet map with point data for nearby AQI stations.

Air Quality Layout


Display current Air Quality data for Shanghai, CN

const view = new aeris.wxblox.layouts.local.AirQuality('#wxblox', {
    request: {
        p: 'shanghai,cn'


The following configuration options are supported by this view:

requestType: object (undefined)An object containing the default weather API request options to use for the views's data request where applicable. These parameters can also be overridden in the load(:params) method when rendering the view using the JavaScript method.``
request.filterType: string (undefined)Filter that is passed to the Weather API query. You can use india or china for these air quality tiers. See the /airquality endpoint for more details.airnow
request.pType: string (undefined)The location that air quality data will be requested for. See supported places for more details.``
enabledType: boolean (undefined)Whether or not the view is enabled. If false then the view will not be rendered and data required for the view will not be requested. This option is typically only applicable for views contained within a parent layout.true
metricType: boolean (undefined)Whether or not to display units in metric. The method setUnits() can be used at runtime once a view has rendered to change the units currently displayed.false


The following methods are supported by instances of this view:


The following events are triggered by instances of this view:
